pf-1000 sEMI AUTO STONE SAW

BEST SELLER

the strongest stone cutting machine in the world

All new for 2021.

HYDRAULIC FUNCTIONS

The Verona Piu Forte Bridge Saw is a  PLC Controlled bridge sawing machine with (3) interpolated axes (X, Y, Z, ) for the processing of marble, granite or other natural and engineered stones. It comes equipped with an automatic Siemens PLC for easy and intuitive use to program precise cutting.

  • 0° - 360° table rotation while being able to stop at any angle

  • 0° - 85° table tilting

  • 0° to 270° head rotation and 0° to  45° auto head tilting.

Its Mono frame structure makes it sturdy and easy to install.  Mono-axial positioning for bridge transaction with encoder.  Automatic rotating table, with fixed locks 45° , also can be locked in any position from 0° - 360°.

2021 PF1000 Transparent.png

PF-1000

 Videos

Technical

Max Diameter of Saw  Blade                          17.5 inch

Table (Working Platform) Dimensions            137.8x82.6 inch

Maximum length of rip cutting                       3500 mm / 137.8 in.

Cutting Depth                                                  40mm/ 4.7 inch

Maximum lifting travel of cutter                     250mm / 9.8 inch

Power of Blade Motor                                      18 kw / 25 hp

Water consumption                                          2M3/h

Gross power                                                      21.3 kw / 28.5 hp

Water pressure                                                 0.2MPA

Machine Weight                                                13853lbs

Adjustable Cut Speed                                      0-12m/min

Machine Dimensions                                        227"x132"x120"

SpecificatioNs
